203mm DHD360-203 DTH Drill Bit with Premium PDC Cutters for Mining & Water Well Drilling
Code No.: DHD360-203
Diameter: 203 mm
Inserts: PDC cutters
Face Design: Concave
Request a quote for detailed information (MOQ, price, delivery)
Share:
203mm DHD360-203 DTH Drill Bit with Premium PDC Cutters for Mining & Water Well Drilling :
From standard cutters to custom drilling solutions, we provide the industry's most reliable PDC products for extreme conditions.
Product Specification
· Bit Type: DTH Hammer Bit
· Code No.: DHD360-203
· Diameter: 203 mm
· Shank Type: DHD360
· Air Holes: 2
· Gauge Buttons: 10 × φ19mm
· Face Buttons: 8 × φ16mm, 6 × φ18mm
· PDC cutter Type: Dome
· PDC Cutter Function: Gauge Protection & Extended Service Life
· Face Design: Concave
· Application: Water Well Drilling, Mining, Construction
The embedded PDC cutter design improves drilling efficiency and bit longevity, making this model particularly suitable for large-diameter blast hole drilling, water well construction, and other high-wear drilling applications.
Product Description
The DHD360-203 DTH hammer bit features a concave face design with 24 dome carbide buttons and DHD360 shank. Engineered for water well, mining, and construction drilling, it delivers good hole deviation control and excellent flushing capacity in medium hard to hard and abrasive rock formations.
Embedded Premium PDC Cutters for Maximum Wear Resistance
The DHD360-203 DTH drill bit is engineered with embedded premium PDC cutters to enhance wear resistance and protect the gauge area during high-impact drilling operations. Working together with heavy-duty dome carbide buttons, the PDC cutters reduce gauge wear, maintain hole accuracy, and improve overall drilling stability in demanding ground conditions.
Designed for large-diameter mining blast holes and deep water well drilling, this hybrid cutting structure provides reliable penetration, excellent impact resistance, and an extended service life. The optimized cutter arrangement minimizes premature wear while maintaining consistent drilling efficiency in medium-hard to hard and abrasive rock formations.
Features
· Concave Face Design – All-around application bit face specifically for medium hard and homogeneous rock formations. Provides good hole deviation control and good flushing capacity.
· 24 Dome Carbide Buttons – 10 gauge buttons (φ19mm) + 8 face buttons (φ16mm) + 6 face buttons (φ18mm) for balanced cutting action and long service life.
· Dome/Hemispherical Buttons – Universal buttons for all rock formations, best suited to hardest and very abrasive rock formations.
· Optimized Air Hole & Channel Design – Air holes and channels designed for efficient cuttings evacuation and fast drilling.
· Load Balanced Cutting Structure – Cutting structure load balanced for maximum power transmission and even drilling.
· Premium Tungsten Carbide – Proven carbide technology and grade selection developed through years of experience in mining industry. Wear resistant carbide allows extended runs between re-grinding.
· Wear Resistant Steel Body – Premium steel and proprietary heat treatment provides high surface hardness and tough core optimal material properties. Wear resistant bit face provides extended service life and button retention.
· DHD360 Shank Type – Compatible with DHD360 series DTH hammers for reliable performance.
· Versatile Applications – Suitable for water well drilling, mining, and construction.
Advantages of Embedded PDC Cutters
· Embedded premium PDC cutters for enhanced gauge protection
· Excellent wear resistance in abrasive rock formations
· Heavy-duty dome carbide buttons for maximum impact strength
· Optimized flushing system for efficient cuttings removal
· Consistent hole accuracy during long drilling operations
· Ideal for mining blast holes and deep water well drilling
